Smart Warehouse Crane Manufactured by Henan Mine
Henan Mine Crane Intelligent Warehouse Crane is designed for the global intelligent three-dimensional warehouse, logistics distribution centers, manufacturing warehouses, high level warehouses, pharmaceutical cold chain warehouses and other scenarios to create the core equipment for automated warehousing, the working level of A5-A7, can be efficiently completed automated access to the goods, intelligent sorting, inventory, material transfer and other full-process operations, a perfect solution to the core of the global warehousing business pain points.
Advantages of Intelligent Warehouse Cranes
Product core positioning and design standards
Core positioning: to provide global warehousing enterprises with specialized automated warehousing solutions, covering the entire process of goods access, picking, inventory, suitable for different scales and types of intelligent warehouses, taking into account the efficiency of warehousing, space utilization and operating costs, helping enterprises to reduce artificial dependence, reduce inventory errors, enhance the level of warehousing intelligence, and suitable for different countries and regions, warehousing design standards and operating modes.
Advantages of Intelligent Warehouse Cranes Manufactured by Henan Mine
Proprietary Core Technologies:
Intelligent control systems, laser positioning modules, scheduling algorithms, and other core technologies are independently developed by Henan Mine. Holding multiple patents, these technologies can be flexibly iterated and upgraded based on customer needs, eliminating reliance on external technologies
Strong Customization Capabilities
Tailored models include narrow aisle, high-bay, low-temperature (-30°C to 0°C, suitable for cold chain storage), and cleanroom (for pharmaceutical/electronics storage) variants based on warehouse dimensions, rack height, and material properties (weight, size, temperature requirements).
Energy Efficiency & Cost Reduction
Equipped with YE4 ultra-efficient copper-core motors, achieving over 30% energy savings compared to traditional motors. Features intelligent sleep technology that automatically enters low-power mode during idle periods, further reducing operational energy consumption;
Rapid Delivery and Implementation:
Dedicated smart storage equipment production facilities equipped with automated manufacturing and debugging systems enable delivery within 20-30 days for standard models and 40-60 days for customized models. Professional technical teams provide end-to-end implementation services—from solution design and installation to system integration—ensuring swift equipment commissioning.
Parameters of Intelligent Warehouse Cranes
pecifications of the Smart Warehouse Crane
| Parameter | Specification | Unit | Remarks |
| Rated Lifting Capacity | 0.5 – 50 | t | Customizable, suitable for pallets, bins and heavy cargo storage |
| Span | 2月15日 | m | Adjustable, suitable for narrow aisle (1.5-3m) and different warehouse layouts |
| Lifting Height | 5 – 35 | m | Customizable according to high-rise shelf height, max 35m |
| Working Class | A6 – A8 | – | Suitable for high-frequency continuous operation in smart warehouses |
| Control Mode | PLC + Unattended / Wireless Remote / Cab Dual Mode | – | 24-hour unattended operation, remote control distance up to 50m, positioning accuracy ±2mm |
| Lifting Speed | 2月15日 | m/min | Frequency conversion stepless speed regulation, stable operation for goods handling |
| Travel Speed (Trolley) | 5月25日 | m/min | High-speed operation, optimized path by intelligent scheduling |
| Travel Speed (Bridge) | 10月30日 | m/min | Stable operation, low noise, anti-collision protection |
| Working Temperature | -20℃ ~ +50℃ | ℃ | Customizable for cold chain (-20℃) and high-temperature environments |
| Power Supply | Customizable 220V-690V, 50/60Hz | V | Three-phase AC, adapt to global power grid standards |
| Material | Q355B High-Strength Steel | – | Shot blasting, ultrasonic welding flaw detection, lightweight and rigid structure |
| Protection Level | IP54 – IP65 | – | Dust-proof, waterproof, suitable for warehouse environment, cold chain optional |
| Certification | ISO, CE, FEM | – | Meet global industrial standards, direct export |
| Packaging | Wooden Box / Plywood Packaging | – | Suitable for ocean transportation |
| Positioning System | Laser Positioning + PLC Control | – | 3-axis positioning (X/Y/Z), positioning accuracy ±2mm, data storage and traceability |
| Safety Device | Limit, Anti-Collision, Fault Self-Diagnosis, Video Monitoring | – | 1080P video surveillance, communication fault protection, emergency stop |
| Integration Capability | WMS/WCS/MES System Compatibility | – | Real-time data synchronization, intelligent scheduling, seamless connection with AGVs |
| Access Cycles | 30 – 60 | Cycles/Hour | 24-hour unattended operation, high efficiency |
What Can Smart Warehouse Crane Offer You?
| Value Category | Specific Benefits | Description |
| Storage Efficiency | High Space Utilization | Compact structure, suitable for narrow aisles (1.5-3m), adaptable to high-rise shelves above 30m, increasing warehouse space utilization by over 60% |
| Operational Efficiency | High-Speed Automated Operation | 30-60 access cycles per hour, 24-hour unattended operation, 5x efficiency improvement compared to manual operation, reducing labor costs significantly |
| Positioning Precision | High-Precision Positioning | Laser positioning technology, positioning accuracy 卤2mm, 3-axis precise positioning (X/Y/Z), ensuring accurate goods storage and retrieval, avoiding damage |
| Intelligent Collaboration | Multi-System Integration | Seamless connection with WMS/WCS/MES systems, realizing intelligent scheduling, automatic operation and real-time inventory synchronization, supporting digital twin platform access |
| Durability & Maintenance | Low Lifecycle Cost | 18+ years design service life, international standard parts, annual maintenance cost only 2%-3% of total equipment price, modular design for easy maintenance |
| Global Compliance | Direct Export & Certification | ISO, CE, FEM certified, customizable power supply, direct export to 80+ countries, complete international technical documents and customs clearance support |
| Customization | Scenario-Adaptable Solutions | Customizable lifting capacity, span, lifting height and fork type, adaptable to e-commerce, cold chain, manufacturing and other storage scenarios |
| After-Sales Support | Global Professional Service | 24/7 multilingual technical support, 72h global spare parts delivery, on-site service for complex faults, ensure smooth warehouse operation |
| Safety & Reliability | Comprehensive Safety Protection | Multiple safety devices (limit, anti-collision, fault self-diagnosis), 1080P video monitoring, communication fault protection, ensuring equipment and goods safety |
| Energy Saving | Green & Energy-Efficient | Intelligent scheduling optimizes operation path, energy consumption reduced by 30% compared to traditional cranes, energy feedback technology available |
| Operational Flexibility | Multi-Cargo Adaptation | Adapt to pallets, bins and other cargo types, support single-deep, double-deep shelf layouts, seamless connection with conveyor lines and AGVs |
Application Scenarios for Intelligent Warehouse Cranes Manufactured by Henan Mine Crane
E-commerce Logistics
Automated goods retrieval, sorting, and high-bay storage for large e-commerce warehouses, optimized for high-frequency inbound/outbound operations during peak seasons like “Double 11” and ‘618
Smart Manufacturing
Automated material handling for automotive parts and electronic component warehouses, seamlessly integrated with production lines to achieve “production-warehousing” synergy
Pharmaceutical Cold Chain
Automated storage and retrieval of medicines and vaccines in low-temperature cold chain warehouses, operating reliably in -30°C to 0°C environments to ensure material safety
Food Processing
Intelligent storage of food ingredients and finished products, eliminating contamination from manual handling and elevating warehouse hygiene standards
Other Applications
Tobacco warehousing, book storage, chemical raw material warehousing (explosion-proof custom models), new energy battery component storage, etc
Your questions regarding the intelligent warehouse crane
-
Is there any flexible payment method and financing program for overseas customers?We provide flexible programs to support installment and financial leasing. We provide full assistance in customs clearance and L/C, provide a full set of information, and support trade terms such as FOB, CFR and CIF.
-
Can Henan Mine Crane be adapted to our narrow aisle warehouse?Absolutely. The equipment is compact and lightweight, suitable for 1.5-3m narrow aisles and more than 30 meters of high-level shelves, can increase the utilization rate of warehouse space by more than 60%, effectively reducing land costs.
-
What is the automation degree of the equipment?It can realize 24 hours unattended. Equipped with PLC intelligent scheduling system, it automatically receives instructions, plans paths, and completes 30-60 access cycles per hour, significantly reducing labor costs.
-
Can it be directly exported to EU countries?It can be directly exported to EU. The equipment is certified by ISO, CE, FEM, no modification is required. We will assist in the whole process of customs clearance, provide English technical data and shipping package.
-
What is the positioning accuracy of the equipment?Positioning accuracy up to ±2mm, support X/Y/Z three-axis positioning, with anti-collision, limit device, can avoid collision, inventory accuracy of more than 99.9%.
-
Can the equipment be docked with our existing WMS/WCS system?Seamless docking is possible. Standard interface is reserved to support synchronization of data with WMS/WCS/MES system without modifying the existing system, and it can also be connected to the digital twin platform.
-
How do overseas customers enjoy maintenance service?Design life is 18 years +, frame warranty is 5 years, electrical 2 years, core mechanical 3 years. Overseas customers can enjoy 7×24 hours after-sales service, 72 hours delivery for emergency spare parts and 48 hours door-to-door service for complex faults.
-
Can it be customized?It can be customized. Modular design, according to the need to customize the lifting capacity (0.5-50t), span and other parameters, plus low-temperature, anti-corrosion and other functions, without the need to transform the warehouse.
-
Is it difficult to maintain the equipment?Maintenance is simple, overseas can complete the basic maintenance. Modularization is easy to disassemble, core components are international common parts, English maintenance manuals are provided, and remote guidance is available for complex faults.
-
Can the equipment run stably in the cold chain warehouse?Stable operation is possible. It can be customized with low-temperature protection, suitable for -20℃~+50℃ environment, low-temperature-resistant electrics, good sealing of the body, and suitable for cold chain storage scenarios.
-
What is the energy consumption of the equipment?Low energy consumption, 30% lower than traditional equipment, with frequency conversion and energy feedback technology, the energy consumption of 24-hour operation is only 70% of traditional equipment, which significantly reduces operating costs.
