Semi-Gantry Crane
Henan Mine Machinery's double-girder semi-gantry crane features an electric hoist as its lifting mechanism. Supported by outriggers on both sides, it operates along ground-mounted rails. Designed for intermittent, repetitive material and equipment handling in general industrial environments, it provides vertical lifting and both longitudinal and lateral movement capabilities. Lifting attachments include hooks, grabs, and electromagnetic chucks to accommodate diverse material handling requirements. Working class: A3 to A5.
Lifting Weight:
5t - 20 t or customized
Span Length
18m - 35 m or customized
Lifting Height
6m - 20m or customized
Work Class
A3 - A6 or customized
Working Temperature Range
-25℃～+40℃
Parameters of Double-Girder Semi-Gantry Crane Manufactured by Henan Mine Machinery
China's premier crane supplier, driving the crane industry forward for 24 years
| Parameter | Specification | Remarks |
| Lifting Capacity | 3 – 20 t | Equipped with CD/MD electric hoist |
| Span | 5 – 30 m | Customizable; Cantilever structure optional |
| Lifting Height | 6 – 18 m | Adjustable according to on-site needs |
| Working Class | A3 – A6 | Suitable for medium and light duty continuous operation |
| Working Temperature Range | -20℃ ~ 40℃ | Suitable for semi-outdoor and workshop extension |
| Lifting Speed | 0.33 – 8 m/min | Single/dual speed optional |
| Traveling Speed | 5 – 30 m/min（Long Travel）; 2 – 20 m/min（Trolley Travel） | Soft start, frequency conversion speed regulation optional |
| Control Mode | Ground pendant, cab control, wireless remote control | Wireless remote control range ≥ 100m |
| Protection Class | IP54（Electrical Components） | Dustproof, waterproof and moisture-proof |
| Delivery Cycle | 25 – 45 days （Standard Model）; 45 – 75 days （Customized Model） | Supported by specialized production line |
Product Introduction of Double-Girder Semi-Gantry Crane Manufactured by Henan Mine Machinery
Henan Mine Machinery's double-girder semi-gantry crane features a core asymmetric structure of “single/double-girder box-type main beam + single-side rigid support legs.” With a lifting capacity of 3-20 tons, customizable spans of 5-30 meters, lifting heights of 6-18 meters, and duty classes A3-A6, it operates reliably in complex environments including temperatures from -20°C to 40°C, high-dust conditions, and semi-open-air settings.
Core Features: Precisely tailored for heavy-duty requirements in small-to-medium confined spaces
- Flexible site adaptation: Utilizes a “single-end supported by factory crane beam track, single-end ground-mounted outrigger” design, eliminating the need for dual-side outriggers like full-gantry cranes, significantly saving lateral space
- Controlled foundation costs: Simple foundation work required only at the ground-supported end. Leveraging existing factory crane beams supports the other end, enabling “one crane covering both indoor and outdoor areas” and avoiding duplicate equipment purchases.
- Universal track compatibility: Factory-end tracks directly match existing bridge crane specifications. Ground-end tracks use standard light rail design for easy installation, drastically shortening site modification cycles.
Henan Mine Machinery’s double-girder semi-gantry crane
Mature transmission system for efficient, smooth operation
- Reliable hoisting mechanism: Standard CD/MD electric hoist with lifting speeds of 0.33-8 m/min, supporting single/dual-speed adjustment
- Balanced Travel Drive: The trolley travel mechanism employs a separate drive solution, with independent drive units for both the ground-level and factory-end sides. Utilizing YSE soft-start motors + LDH precision reducers, it achieves travel speeds of 5-30 m/min with smooth, shock-free starts and stops, preventing swaying of heavy loads.
- Energy-Efficient, Low-Noise Design: Core motors use YE3 high-efficiency models, reducing energy consumption by over 25% compared to standard motors.
Henan Mine Machinery’s double-girder semi-gantry crane
Comprehensive Safety Protection for Semi-Outdoor Operations
- Multi-level Safety Interlocks: Standard features include load limiter, four-level hoist height limiters, trolley/girder travel limiters, and polyurethane buffers for end-to-end safety. The hoisting mechanism employs a normally closed electromagnetic disc brake that engages instantly upon power loss, eliminating hook slippage risks.
- Enhanced semi-outdoor protection: Electrical control cabinets feature IP54-rated enclosures with dehumidification systems, offering dust, water, and moisture resistance. Equipment automatically locks when wind speeds exceed 15m/s.
- Comprehensive emergency safeguards: Emergency stop buttons are strategically placed throughout (control room, remote controller, worksite) for rapid response to unforeseen incidents.
Henan Mine Machinery’s double-girder semi-gantry crane
What Can Henan Mine Machinery's Double-Girder Semi-Gantry Cranes Offer You?
| Value Category | Specific Benefits | Description |
| Space Utilization Improvement | 30%+ higher space utilization; Seamless indoor-outdoor transfer | Single-side outrigger design saves lateral space; Covers workshop and outdoor yard, avoiding repeated equipment purchase and improving site utilization |
| Construction & Investment Cost Reduction | 25%-30% lower foundation cost; 15%-20% lower overall investment | Relies on existing factory crane beams, avoiding double-side outrigger construction; Modular installation shortens transformation cycle and reduces construction cost |
| Operational Efficiency Enhancement | 20% higher hoisting efficiency; 40% shorter material transfer cycle | Soft start and stable operation ensure precise hoisting; Seamless indoor-outdoor transfer reduces material handling links; Multiple control modes adapt to different operation scenarios |
| Operational Cost Reduction | 25%+ energy saving; 40% lower maintenance cost | High-efficiency motor reduces energy consumption; Simple structure and standardized components facilitate maintenance; Long-life wearing parts reduce replacement frequency and cost |
| Safety & Reliability | 95% lower safety accident rate; Stable operation in semi-outdoor environment | Multi-layer safety interlock system eliminates potential hazards; IP54 protection level and anti-rust coating adapt to complex semi-outdoor environment; Emergency stop devices ensure quick response to risks |
| Scenario Adaptability | Adapt to narrow sites and old factories; Customizable for multiple industries | Customizable parameters and optional components adapt to machinery processing, building materials storage and other scenarios; Provide crane beam verification and reinforcement solutions for old factories |
Quality and Service Assurance for Henan Mine
- Stringent Quality Control: Each unit undergoes 1.25x static load testing, 1.1x dynamic load testing, and safety device interlock verification before shipment. Critical welds receive 100% ultrasonic testing, accompanied by comprehensive inspection reports and product certification, meeting special equipment regulatory standards.
- End-to-End Implementation Services: Complimentary on-site facility surveys and crane beam load capacity calculations, delivering customized solutions.
- Nationwide Dedicated After-Sales Network: Specialized service stations for small and medium-sized cranes established in major industrial cities across China. Staffed by over 120 professional after-sales engineers, all with MB series maintenance experience, providing 24-hour response.
- Warranty Commitment: 1-year warranty for the entire machine; 3-year warranty for core components (main beam, hoisting mechanism, traveling mechanism); 5-year warranty for core safety devices (brakes, load limiters). Free repair or replacement for non-human-induced damage during the warranty period.
Henan Mine Machinery’s double-girder semi-gantry crane
Parameter Table for Double-Girder Semi-Gantry Crane Manufactured by Henan Mine Machinery
| Lifting capacity | T | 3 | 5 | 10 | 16 | 20 | ||
| Operation type | Handle/remote control/cab | |||||||
| Speed | Hoist lifting | m/min | 8 ,8/0.8 | 8,8/0.8 | 7,7/0.7 | 3.5 | 3.5 | |
| Hoist travelling | m/min | 20 | 20 | 20 | 20 | 20 | ||
| Crane travelling | 20 | 20 | 20 | 20 | 20 | |||
| 30,40 | 30,40 | 30,40 | 30,40 | 30,40 | ||||
| Motor | Hoist lifting | Type /kw | ZD41-4/4.5 | ZD141-4/7.5 ZDS10.8/4.5 | ZD151-4/13 ZDS11.5/4.5 | ZD151-4/13 | ZD152-4/18 | |
| Hoist travelling | ZDY12-4/0.4 | ZDY121-4/0.8 | ZDY21-4/0.8×2 | ZDY121-4/0.8×2 | YZD-4/0.8×4 | |||
| Trolley travelling | ZDY21-4/0.8×2 | YZR132M1-6/2.2×2 | YZR160M1-6/6.3×2 | YZR160M1-6/6.3×2 | YZR160M1-6/6.3×2 | |||
| ZDY21-4/1.5×2 | YZR132M2-6/3.7×2 | YZR160M2-6/8.5×2 | YZR160M2-6/8.5×2 | |||||
| ZDR22-4/1.5×2 | YZR132M2-6/3.7×2 | YZR160M1-6/6.3×2 | YZR160M2-6/8.5×2 | YZR160M2-6/8.5×2 | ||||
| ZDR24-4/2.2×2 | YZR160M1-6/5.5×2 | YZR160L2-6/11×2 | YZR160L2-6/11×2 | |||||
| Electric hoist | Type | CD1/MD1 | CD1/MD1 | CD1/MD1 | HC/HM | HC/HM | ||
| Lifting height | m | 6,9,12 | ||||||
| Work classifications | A3,A4 | |||||||
| Power | 380V 50HZ 3phase AC or according to customers’ demand | |||||||
Advantage display
Product Advantages Overview
Large-Tonnage Bearing
Rated lifting capacity ranges from 5T to 500T, and larger tonnages can be
customized for special needs. Adopting high-manganese steel main beam and
reinforced
Intelligent Precision Control
quipped with a PLC intelligent control system, supporting millimeter-level
positioning and automatic loading/unloading. Lifting and running speeds can be
flexibly adjusted, and
Multiple Safety Protections
Integrates multiple safety mechanisms such as overload protection, limit
protection,
anti-fall protection and emergency braking, equipped with high-definition
monitoring
and fault
Longer Service Life
Core components are made of high-quality materials such as wear-resistant alloy
and corrosion-resistant steel, reinforced by heat treatment process. The
electrical system
Detailed Drawing of Double-Girder Semi-Gantry Crane Manufactured by Henan Mine Machinery
China's premier crane supplier, driving the crane industry forward for 24 years
Application Scenarios for Henan Mine Machinery's Double-Girder Semi-Gantry Cranes
Henan Mine Machinery's double-girder semi-gantry cranes are compact lifting equipment specifically designed for space-constrained environments, featuring easy installation, cost-effectiveness, and smooth operation.
-
Outdoor Loading Docks of Machining WorkshopsSuitable for connecting workshops with outdoor loading docks in small-to-medium machining plants and agricultural machinery factories. Used for raw material transfer and finished product loading. Equipped with variable frequency speed control systems for smooth, shock-free operation, preventing damage to precision components during transfer.
-
Peripheral Zones of Automotive Parts/Electronic Components Assembly WorkshopsFacilitates cross-area material transfer for automotive parts factories (e.g., stamped components, transmission housings) or lifting of large cabinets and equipment accessories in electronics manufacturing plants.
-
Small-to-Medium Steel/Shaped Material Yards (Adjacent to Factory Buildings on One Side)Suitable for open-air yards at township-level steel processing plants or wrought iron workshops. One side utilizes factory tracks, while the other side operates along edge tracks with outriggers, lifting 2-20 ton materials like round bars, angle steel, and steel plates.
-
Small-scale production areas for building materials/precast componentsUsed in localized open-air work zones at concrete precast plants or stone factories for lifting precast floor slabs, stone blocks, and similar materials.
-
Small Construction Equipment Repair Shops / Automotive Service StationsUsed in semi-open repair zones of workshops to lift heavy components like car engines and excavator parts.
-
Temporary Lifting Zones for Small-Scale Infrastructure ProjectsSuitable for small construction sites like residential developments or rural road upgrades. Serves as temporary lifting equipment for materials weighing 2-10 tons, including rebar, cement pipes, and construction machinery parts.
-
Peripheral Areas of Small-to-Medium WarehousesUsed in peripheral zones of agricultural supply warehouses and hardware component warehouses to lift bulk fertilizer bags, heavy machinery equipment, and other materials, enabling rapid loading/unloading between warehouses and transport vehicles.
-
Hydroelectric/Small Power Plant Auxiliary AreasUsed for transferring generator components in hydroelectric plants and maintaining equipment in small power stations, lifting transformers, generator parts, and similar materials.
-
Model Selection Recommendations:Select 2-20 ton models based on material weight, allowing 10-20% safety margin. Prioritize confirming outrigger clearance from walls in confined spaces. Henan Mine offers on-site surveys to precisely match models with factory track conditions and operational environments.
Crane Operation Demonstration
China's premier crane supplier, driving the crane industry forward for 24 years
How to Choose the Best Crane Manufacturer in China
Henan Mine Crane Co., Ltd. is a professional manufacturer and service provider of cranes and material handling products. Integrating R&D, design, manufacturing, sales, and service, we deliver comprehensive solutions and full-lifecycle support to our customers.
-
1Clarify Your Crane NeedsThoroughly understand your lifting requirements (load details, frequency, and workspace environment) before approaching crane manufacturers.
-
2Determine Crane Service ClassCalculate the required crane service class based on your operational intensity to ensure optimal performance and longevity.
-
3Explore Crane Supplier Custom Features:Investigate available customization options and special features to enhance safety, efficiency, and precision for your specific application.
-
4Assess Crane Factory Engineering CapabilityEvaluate the manufacturer's engineering strength to ensure they can design a suitable solution tailored to your needs.
-
5Verify Quality & Compliance of Crane CompanyCheck the crane manufacturer's manufacturing quality, certifications, and compliance with international standards and your local safety regulations.
-
6Ensure Support & ReferencesConfirm the manufacturer provides reliable after-sales support and has a proven track record with positive references in your industry or region.
Why We Are More Trustworthy
Henan Mine Crane Co., Ltd. is a professional manufacturer and service provider of cranes and material handling products. Integrating R&D, design, manufacturing, sales, and service, we deliver comprehensive solutions and full-lifecycle support to our customers.
Experienced company
Established in 2002, Henan Mine Crane Factory is a high-tech crane enterprise. Using advanced global design and manufacturing tech, we craft top-quality single/double-beam cranes and electric hoists.
Professional team & equipment
Our 1.62 million ㎡ factory has 3,500+ staff, 200 senior engineers, and 428+ global sales/service points. With 2,000+ processing machines handling 20+ processes, we ensure excellence.
Productive capacity
The annual output of cranes is over 80,000 units. The company produces and sells more than 11000 double beam and gantry cranes annually, More than 73000 single beam cranes, and More than 100000 sets (sets) of single and double beam electric hoists and accessories.
Customized design services
We know the right crane is key. Our engineers partner with clients to design and build cranes tailored to specific needs, ensuring optimal performance.
Why Our Cranes Earn Customers' Trust
Henan Mine Crane Co., Ltd. has a strong technical team with over 10 top experts and 200+ mid-to-senior engineers. They've obtained over 700 national patents and provincial-level tech achievements, with over 670 authorized patents. Henan Mine Crane Factory led/participated in over 100 standard formulations/revisions, won the China Standard Innovation Contribution Award, and is a key member of multiple lifting machinery standardization committees. Dr. Xu Lei serves as Deputy Leader of the ISO/TC96 Domestic Technical Counterpart Expert Working Group.
The services we provide
China's premier crane supplier, driving the crane industry forward for 24 years
Free customization scheme
The professional engineer team communicates in depth to understand needs, and provides
one-stop customized solutions including 3D model design, technical parameter calculation
Regular Maintenance Reminder
Establish customer equipment files, and regularly send maintenance reminders based on
equipment usage time and operation intensity. Provide detailed maintenance manuals and
video tutorials
Technical support consultation
Provide 7×12-hour online technical consultation service. Senior consultants answer
questions in real time regarding product selection, parameter matching, installation
specifications
Free customization scheme
The professional engineer team communicates in depth to understand needs, and provides
one-stop customized solutions including 3D model design, technical parameter calculation
Our Patents and Certifications
China's premier crane supplier, driving the crane industry forward for 24 years
Customer Testimonials & Top Choices
China's premier crane supplier, driving the crane industry forward for 24 years
Related Product Recommendations
China's Premier Crane Supplier, Empowering the Lifting Industry for 24 Years
MGB hook-type semi-gantry crane
Henan Mine Machinery's MGB hook-type semi-gantry crane is designed for intermittent, repetitive loading, unloading, and handling of materials and equipment in general operating environments. It features vertical lifting, longitudinal, and lateral movement capabilities, primarily serving material handling and transfer in wall-adjacent areas. It offers exceptional adaptability to site conditions.
KSMB semi-gantry crane
Henan Mine Machinery's KSMB semi-gantry crane is currently one of the most widely used lifting machines. Equipped with an electric hoist as its lifting mechanism, it runs on ground rails supported by outriggers on both sides. It can load, unload, and transport materials and equipment intermittently and repeatedly in general working environments, featuring vertical lifting, longitudinal, and lateral movement capabilities. Gripping devices include hooks, grabs, and electromagnetic chucks to accommodate diverse material handling requirements. Outriggers with cantilevers facilitate transferring items from the span to the outside area, though cantilevers are optional. Working class: A3–A5.
MGBE semi-gantry crane
Henan Mine Machinery's MGBE semi-gantry crane is currently one of the most widely used lifting machines. Supported by outriggers on both sides running on ground rails, it can load, unload, and transport materials and equipment intermittently and repeatedly in general outdoor environments. It features vertical lifting, longitudinal, and lateral movement capabilities. Lifting attachments include hooks, grabs, and electromagnetic chucks to accommodate diverse material handling requirements. Depending on operational needs, outriggers may be fitted on both sides or only one side to facilitate transferring items from the center span to the outer span. Outriggers can also be omitted. Working classes range from A3 to A8
Become our distributor
Array
Become our agent
Full range of lifting equipment, international standard quality and ample production capacity, ensuring worry-free agency support.
Professional cross-border after-sales team + global parts warehouses, 24-hour response, full-cycle service to help you effortlessly expand your market.
Generous agency policies + regional exclusive protection, guaranteeing your profits and worry-free cooperation.
We sincerely invite global partners with resources to join hands, jointly develop the global crane market, and achieve mutual benefit and win-win outcomes!
Your Top Concerns About Henan Mine Machinery's Double-Girder Semi-Gantry Cranes and Professional Answers
China's premier crane supplier, driving the crane industry forward for 24 years
-
Our facility is an older factory building. We're unsure if it can support the MB₁ semi-gantry crane. Can you provide assurance?Professional Answer: Absolutely! Addressing load-bearing concerns for crane beams in older factory buildings is a key focus area we specialize in. We provide comprehensive verification calculations and compatibility guarantees, ensuring absolutely no impact on the structural safety of your facility. We will sign a dedicated agreement clearly stipulating that any damage to the crane beam caused by equipment design or installation will be fully covered by us for repairs and compensation.
-
Half our workspace is indoors and half outdoors. Are the electrical components of the semi-gantry crane prone to failure?Professional Answer: We've already addressed this issue specifically. The electrical components are fully protected and can withstand semi-open environments with dust and rain without frequent failures! We'll also optimize protection based on your local climate conditions—for example, adding rain eaves to control cabinets in rainy areas or upgrading sealing gaskets in dusty regions to further enhance protection.
-
We require 28m long-span lifting. Since the MB₁ semi-gantry crane has only single-side outriggers, will the main beam sway or deform under heavy loads?Professional Answer: A 28m span poses no issues whatsoever. The main beam will not sway or suffer permanent deformation, ensuring full stability under heavy loads! We also optimize the main beam's camber based on your material weight and lifting frequency, further enhancing operational stability
-
How long does it take to install a semi-gantry crane?Professional Answer: Installation requires no production line shutdown and causes zero impact on output! Our modular design reduces installation time by 30% compared to industry averages. A standard 28m span unit completes installation and commissioning within 10-15 days. For extremely tight schedules, we can deploy two teams working in parallel to further accelerate the timeline.
-
Is the semi-gantry crane difficult to operate?Professional Answer: Operation is extremely straightforward. Operators can quickly master it after 2-3 days of specialized training! The operating logic aligns closely with electric hoist single-girder cranes, and we've implemented user-friendly optimizations to lower the learning curve. Post-training, we provide one day of on-the-job guidance to ensure full operator proficiency.
-
How does the cost-effectiveness of semi-gantry cranes compare to full-gantry cranes of the same tonnage?Professional Answer: The MB₁ semi-gantry crane offers unmatched cost-effectiveness. Long-term use yields significant annual savings, typically recouping the additional investment within 2-3 years! Space utilization benefits include freeing up the dual-leg support area for expanded storage or production zones, indirectly generating revenue.
-
We plan to add intelligent monitoring functionality later. Can the semi-gantry crane be upgraded?Professional Answer: Absolutely! The MB₁ semi-gantry crane's electrical control system includes reserved open interfaces, supporting post-installation of intelligent monitoring systems. The upgrade process is straightforward and does not disrupt normal equipment operation!
-
We're concerned about production disruptions if equipment fails later. How responsive is your after-sales service?Professional Answer: Rest assured—our comprehensive after-sales response and spare parts supply system minimizes downtime losses. Our preventive maintenance service includes annual maintenance agreements, where we conduct regular on-site inspections to proactively identify and resolve potential issues before they escalate.
Operating Manual for MG Double-Girder Gantry Crane Manufactured by Henan Mine
China's premier crane manufacturer, driving high-quality development in the crane industry for 24 years
-
Each crane must display a rated load capacity plate in a conspicuous location.
-
No personnel are permitted on the girder during operation, nor may the hook be used to transport persons
-
Operation is prohibited without a valid operator's license or under the influence of alcohol.
-
Operators must maintain full concentration during operation; talking, smoking, or engaging in unrelated activities is strictly forbidden.
-
Keep the crane clean and tidy; do not store equipment, tools, flammable materials, explosives, or hazardous substances haphazardly.
-
Do not overload the crane.
-
When operating along obstacle-free paths, the hook, lifting device, or bottom surface of the load must remain at least 2 meters above ground level. When crossing obstacles, the load must clear the obstacle by at least 0.5 meters
-
For loads under 50% of rated capacity, both lifting mechanisms may operate simultaneously. For loads exceeding 50% of rated capacity, only one mechanism may operate.
-
.For bridge cranes equipped with main and auxiliary hooks, do not simultaneously raise or lower both hooks (except under special circumstances).
-
Welding or hammering on suspended loads, or working beneath suspended loads, is prohibited (except when properly supported).
-
Inspection or maintenance work may only be performed after power has been disconnected and a “Do Not Operate” sign is displayed on the power switch. If live work is unavoidable, implement safety measures and assign dedicated supervision.
-
Do not throw objects from the vehicle indiscriminately.
-
Regularly inspect limit switches and interlock protection devices.
-
Do not use limit switch impact as a stopping method.
-
Do not lift or lower loads when hoist brakes malfunction.
-
Do not operate the hoist above personnel or equipment.
-
When welding any part of the crane, use a dedicated ground wire; do not use the crane body as a ground.
-
When the hook is at its lowest position, ensure at least two full turns of safety rope remain on the drum.
-
Cranes must not collide with each other; using one crane to push another into operation is strictly prohibited.
-
When lifting heavy objects, molten metal, explosives, or hazardous materials, first slowly raise the load 100–200 mm off the ground to test brake reliability.
-
Maintenance and inspection lighting must operate at voltages below 36V.
-
All electrical equipment enclosures on bridge cranes must be grounded. If trolley rails are not welded to the main girder, grounding measures must be implemented. Grounding conductors may use galvanized flat iron with a cross-sectional area exceeding 75mm², bare copper wire of 10mm², or galvanized round steel exceeding 30mm². The operator's cab or crane body shall have more than two grounding points. The grounding resistance from any point on the crane to the power supply neutral point shall be less than 4Ω.
Directly state your needs and receive professional advice!
30 Years of Lifting R&D, Following Strict European Standards, Intelligent
Empowerment
for Heavy Loads, Providing Global Safe & Excellent Solutions
The project was delivered on time and landed safely
Henan Mine Machinery's double-girder semi-gantry crane addresses lifting coverage and space utilization challenges. Eliminating the need for extensive site modifications, it helps enterprises reduce infrastructure costs and maximize spatial efficiency. This essential equipment is a must-have for small and medium-sized manufacturing and warehousing businesses operating in space-constrained environments.
Improve efficiency
Break through operational bottlenecks and improve overall project progress efficiency
Avoiding risks
Build a solid safety line and avoid potential risks of high-risk operations
Delivery
Adapt to diverse working conditions and ensure stable project implementation and delivery
