Electromagnetic Overhead Cranes With Magnet Beam
I. Product Introduction of Henan Mine Machinery’s Overhead Rotating Electromagnetic Beam Crane
Henan Mine Machinery’s Overhead Rotating Electromagnetic Beam Crane is a high-efficiency intelligent lifting solution specifically engineered for handling magnetic materials without strapping. It is core-optimized for transporting steel plates, structural steel, steel billets, scrap steel, and similar materials, finding extensive application in steel metallurgy, shipbuilding, port yards, heavy machinery processing, and related industries.
Henan Mine Machinery’s Overhead Rotating Electromagnetic Beam Crane
The equipment innovatively adopts an integrated “upper rotating trolley + electromagnetic beam” design, incorporating core technologies such as 360° full-rotation drive, intelligent electromagnetic control, and multiple safety redundancies. This design completely resolves the pain points of traditional lifting methods—such as cumbersome material bundling, difficult angle adjustments, and low operational efficiency—enabling a fully efficient and coordinated “adhesion-rotation-positioning-placement” material handling process.
Henan Mine Machinery’s Overhead Rotating Electromagnetic Beam Crane
Backed by Henan Mine Machinery’s precision manufacturing system—featuring over 600 intelligent processing units—the product holds multiple national and industry certifications including GB/T 14405-2011 and JB/T 14897-2024 “Safety Technical Specifications for Lifting Magnets.” It has successfully served flagship projects such as subsidiaries of Baowu Group and major shipyards in the Yangtze River Delta, establishing itself as the preferred equipment for intelligent material handling upgrades.
Henan Mine Machinery’s Overhead Rotating Electromagnetic Beam Crane
Core Technical Advantages
- 360° Precision Rotation for Full Coverage: Utilizing an upper-rotation drive structure with high-precision slewing bearings and variable-frequency motors, it achieves continuous 360° stepless rotation. Adjustable rotation speed ranges from 0.5 to 2 r/min with positioning accuracy of ±3 mm, effortlessly meeting multi-angle material alignment and precise workstation adaptation needs (e.g., 90° turning and cutting of steel plates in shipyards, multi-angle stacking of slabs in steel mills). The rotation mechanism incorporates dual braking protection, automatically locking upon positional completion to prevent accidental movement during operation and ensure safety.
- Intelligent Electromagnetic Adhesion: Dual Assurance of Safety and Energy Efficiency: The electromagnetic beam is equipped with a high-efficiency, energy-saving electromagnetic chuck. Utilizing copper-core coils and vacuum-poured insulation technology, it achieves Class H insulation with stable holding force and an annual decay rate below 0.5%. Features an intelligent power-off magnetic retention system that automatically switches to emergency power during sudden outages, maintaining magnetic force for at least 15 minutes (far exceeding national minimum standards) to prevent material drop. After stable material adhesion, it automatically switches to low-current maintenance mode, achieving 20%-30% energy savings compared to traditional electromagnetic chucks.
- High-strength structural design for heavy-duty applications: Main beams utilize Q345B/Q690 high-strength steel, optimized through finite element analysis and full annealing treatment to eliminate welding stresses, delivering 30% improved torsional resistance over conventional structures. The electromagnetic beam adopts a box-type beam structure with customizable lengths based on material dimensions. It supports multi-chuck grouped excitation control, with a single unit’s rated lifting capacity ranging from 5 to 50 tons. This enables one-time lifting and transport of various material specifications without manual strapping, boosting operational efficiency by over 30%.
- Intelligent Control Upgrade for Streamlined Maintenance: Utilizes a PLC + variable frequency control system supporting triple control modes—wireless remote, cab operation, and remote monitoring—for flexible adaptation to diverse work environments. Equipped with an intelligent fault diagnosis system that continuously monitors parameters including electromagnetic chuck status, rotation mechanism temperature, and motor load. Automatically alerts operators and pushes fault cause notifications during anomalies. Key electrical components feature IP55 protection rating, ensuring reliability in harsh conditions such as high temperatures, heavy dust, and high humidity.
Henan Mine Machinery’s Overhead Rotating Electromagnetic Beam Crane
Suitable Applications
Specifically engineered for lifting unbundled magnetic materials, widely used in:
① Steel Mills: Transferring, stacking, and feeding slabs, billets, and structural steel into hot rolling mills;
② Shipyards: Handling large steel plates and structural components for cutting stations;
③ Ports/Yards: Loading, unloading, and transferring bulk materials like scrap steel and iron ore;
④ Heavy Machinery Factories: Precision lifting and positioning of molds and cast iron components. Operates in environments from -20°C to 40°C, withstands high-temperature material radiation below 650°C, and meets A6-A7 duty cycle requirements for 24/7 continuous operation.
Henan Mine Machinery’s Overhead Rotating Electromagnetic Beam Crane
Benchmark Case Endorsements
Customized overhead electromagnetic beam crane for a Baowu Group steel base, tailored for slab transfer operations. Post-commissioning, achieved unbundled slab handling, reducing single transfer time from 15 to 8 minutes—a 47% efficiency gain. The 360° rotation precisely matches stacking angle requirements, controlling stacking errors within 5mm. No material drop incidents occurred, earning high recognition from the client’s operations department.
With its stable performance, this series has become bulk-purchased equipment for multiple large shipyards and steel enterprises in the Yangtze River Delta and Bohai Rim regions.
Henan Mine Machinery’s Overhead Rotating Electromagnetic Beam Crane
Henan Mine Machinery’s Overhead Rotating Electromagnetic Beam Crane
Your Top Concerns About Henan Mine Machinery's Overhead Rotating Electromagnetic Beam Crane and Professional Answers
-
Will the electromagnetic chuck lose magnetism and cause material to fall during sudden power outages?Answer: Absolutely no loss of magnetism or material drop will occur, as our magnetic retention capability far exceeds national standards. Our equipment incorporates a dual power failure magnetic retention system: First, it features an independent emergency power supply that automatically and seamlessly switches over during sudden power outages, ensuring continuous power to the electromagnetic chuck. Second, it employs a “permanent magnet + electromagnetic” hybrid retention design. Even if the emergency power fails, the permanent magnets still provide stable holding force.
-
What is the maximum rotation angle achievable by the upper rotation mechanism? Will there be any shaking or positioning inaccuracies during operation?Answer: The upper rotation mechanism enables 360° continuous stepless rotation with precise positioning and smooth operation, eliminating swaying risks. Its core utilizes high-precision slewing bearings and variable-frequency drive motors, allowing precise rotation speed adjustment to prevent start-stop impact-induced sway. Dual protection from photoelectric positioning sensors and mechanical limit switches ensures positioning accuracy of ±3mm, fully meeting requirements for precise stacking and workstation docking.
-
We primarily handle steel plates of varying thicknesses and loose scrap steel. Is this equipment compatible? Is the magnetic holding force sufficient?Answer: It is fully compatible with stable and ample magnetic holding force. Our electromagnetic beam supports multi-suction cup grouped excitation design, allowing flexible switching of magnetic modes based on material type. For your specific application, we can customize the number and layout of suction cups to ensure 100% compatibility.
-
Are maintenance costs high? Do we need specialized technicians?Answer: Maintenance costs are 30% lower than industry peers. Standard operators can handle maintenance after brief training—no dedicated technicians required. We provide standardized maintenance manuals and free on-site training, plus an intelligent fault diagnosis system that remotely alerts for potential issues, reducing unnecessary maintenance expenses
-
Can parameters like rated lifting capacity and span be customized?Answer: Full customization is supported with industry-leading lead times. Customization process: Discuss requirements 3-5 days in advance. Our technical team conducts on-site surveys, performs 3D modeling optimization based on your workshop layout and material characteristics, and achieves operational readiness in just 35 days
-
What advantages does the overhead rotating electromagnetic beam offer compared to traditional grab cranes?Answer: It delivers over 30% higher operational efficiency and reduces total lifecycle costs by 40%, offering significant advantages. Efficiency: Grab cranes risk spillage when handling loose scrap steel, whereas our electromagnetic system eliminates spillage risks and subsequent cleanup costs. Cost-wise: First, labor costs decrease by 60%. Second, energy savings reduce annual electricity consumption by up to 12,000 kWh through current reduction after stable adhesion. Third, maintenance costs are low, with annual expenses reduced by 30% compared to grab cranes, while increased efficiency boosts production capacity.
-
Can the equipment integrate with our existing MES production system? Can it achieve intelligent collaborative operations?Answer: Seamless integration is fully achievable, enabling end-to-end intelligent collaboration. The equipment features a standardized OPC UA communication interface for direct connection to your MES production execution system and WMS warehouse management system. The system automatically adjusts task priorities based on production progress, eliminating process delays. Integration takes only 7-10 days, with our dedicated technical team managing the entire commissioning process without disrupting existing production lines.
-
How is your after-sales service guaranteed?Answer: We provide 24/7 full-lifecycle concierge-style after-sales service, ensuring rapid response and efficient resolution of issues. With 12 regional technical centers established in steel and shipbuilding hubs, staffed by over 150 professional maintenance technicians, we offer long-term support. Equipment comes with a 1-year warranty covering free replacement of non-human-damaged parts. Additionally, we provide 3-5 year annual maintenance packages with scheduled on-site inspections and servicing.
-
Can we visit an actual project site to observe equipment operation before purchasing?Answer: Absolutely. We warmly welcome your on-site visits, which follow a simple and convenient process. Our technical team will accompany you throughout, providing live explanations of core technologies, operational parameters, and daily maintenance essentials. We will coordinate with project operators to demonstrate full workflow procedures and address all your questions one-on-one.
