YX type metallurgical bridge crane
Henan Mine Crane YX type metallurgical bridge crane is designed for the metallurgical industry to create a bridge-type special equipment, working level A6-A7, can complete the box hanging, transfer, dumping the whole process of operation, to match the smelting workshop high temperature, high load, high frequency working conditions, a perfect solution to the global metallurgical enterprises, the core of the pain of the furnace mouth material transfer!
Lifting Capacity
5t - 50t or customized
Span
7.5m - 35m or customized
Lifting Height
6m - 20m or customized
Work Class
A6 - A7 or customized
Power Supply
380V/50Hz; 220V-660V/60Hz
Parameters of YX type metallurgical bridge crane Manufactured by Henan Mine Crane
China's Premier Crane Manufacturer, Driving High-Quality Development in the Crane Industry for 24 Years
| Parameter | Specification | Remarks |
| Rated Lifting Capacity | 5t – 50t | Customizable for metallurgical material box |
| Span | 7.5m – 35m | Extended for large smelting workshop |
| Lifting Height | 6m – 20m | For material box hoisting & turnover |
| Working Class | A6 – A7 | High intensity continuous smelting operation |
| Structural Form | Single/double trolley, bridge type | Double trolley for synchronous lifting & turnover |
| Control System | PLC + HMI touch screen + WLK controller | Zero position self-reset & lock device |
| Motor Insulation Class | Class H | High temperature resistant for furnace area |
| Wheel Process | Forging and rolling composite | 20% longer service life |
| Weighing Function | High precision electronic scale | Real-time weight display & statistics |
| Heat Protection | High temp material + heat insulation cover | Resist furnace mouth radiation heat |
| Trolley Control | Double trolley synchronous control | Turnover, synchronous lifting & traveling |
| Power Supply | 380V/50Hz; 220-660V/50-60Hz | Global power grid customizable |
| Protection Level | IP54 | Dust-proof & high temperature resistant |
| Certification | National metallurgical crane standard | Assist CE/ISO9001/GOST/FEM |
Henan Mine Crane manufactured YX type metallurgical bridge crane Product Introduction
Henan Mine Crane YZ Type Metallurgical Overhead Crane is strictly follow the metallurgical bridge crane standard research and development of special materials transfer equipment, mainly used for smelting process of the furnace mouth materials transfer, Henan Mine Crane in the field of metallurgical materials transfer of the main products.
This metallurgical high-temperature hopper cranes for smelting workshop for the harsh environment to do full-dimensional upgrades, service life than the traditional forging wheels increased by 20%; lifting mechanism equipped with electronic scales, real-time display and statistics of the weight of the material, accessories universal global standards, suitable for the global iron and steel mills, smelting plants, non-ferrous metal processing plants, is the cost-effective special solutions for metallurgical material transfer.
Product core positioning and design standards
The core positioning of YX type metallurgical bridge crane is to provide high-temperature-resistant, high-load and high-efficiency material box lifting solutions for global metallurgical smelting enterprises.
Core structure and functional design
- Intelligent control system: the linkage table is equipped with PLC module + human-machine interface touch screen, with WLK-type master command controller, clear feel, clear gear, equipped with zero position self-recovery and locking device, to eliminate malfunction from the operation side, the whole vehicle adopts intelligent communication control, self-diagnosis of faults, and visualization of operation data.
- High-temperature resistant protection system: the key force parts and transmission parts are made of high-temperature resistant alloy; the motor and electric control box are equipped with heat-insulating protective cover, and the motor insulation level reaches H class, which can withstand the high-temperature radiation in the furnace mouth area for a long time, and the high-temperature environment has no attenuation and no faults.
- Long-life wheel structure: the wheels are made of forged and milled composite technology, with denser internal grains, higher surface hardness, wear-resistant and anti-fatigue, and the service life is increased by 20% compared with the traditional forged wheels, which greatly reduces the replacement frequency and maintenance cost.
- Real-time weighing function: the lifting mechanism integrates high-precision electronic scales, which can display the weight of lifted materials in real time, and support weight statistics, data recording, and overloading alarm, so as to accurately control the weight of materials being transferred and avoid the risk of overloading.
- Synchronized control of double trolley: Equipped with advanced electrical control system of double trolley, it can run independently, or realize material box overturning, synchronized lifting, synchronized walking, to meet the operational needs of different material transfer and dumping, and enhance the efficiency of multi-purpose machine.
- Heavy-duty stable structure: the bridge is welded with high-strength steel profile and processed by stress-elimination, which is rigid and deformation-resistant, and is suitable for the smelting and transferring working conditions with high load and high frequency, and it runs smoothly without shaking.
Core product advantages
- High-temperature resistant and strong adaptability: H-class insulated motor + thermal protection, resistant to high-temperature radiation at the furnace mouth, 24-hour continuous operation without failures.
- Long life and low maintenance: forged grinding wheel life increased by 20%, generalized parts design, convenient global procurement, low maintenance cost.
- Intelligent and precise operation: PLC intelligent control + electronic weighing + double trolley synchronization, accurate and efficient transfer, dumping and lifting.
- Safety against misoperation: zero self-locking master controller + overload protection + double limit, all-round protection of high-risk operation safety.
- Global Adaptation and Export: Supporting international certification and global grid customization, it can be directly exported to Europe, America, Southeast Asia, the Middle East and other regions.
Global Adaptation and Application Scenarios
- Application Scenario: Global metallurgical steel mills, smelting workshops, non-ferrous metal smelting plants, used for transferring materials at the furnace mouth, dumping material boxes, lifting heavy materials, etc.
- Standard adaptation: support CE, ISO9001, GOST, FEM and other international certifications, power supply 220V-660V/50-60Hz fully customized, adapted to the global power grid.
- Environmental adaptation: high temperature resistance, high dust, resistance to minor corrosion, coastal salt spray environment can be upgraded to anti-corrosion, global smelting scenarios can be used in a stable way.
Global exclusive supporting services
- Provide a full set of technical data, installation drawings and operation manuals in English/Spanish/Arabic;
- 7×24 hours global remote video installation and debugging guidance, door-to-door installation is available;
- Equipment parts center in Germany, the United States, Malaysia, the United Arab Emirates, 72 hours of rapid global delivery;
- Multi-language after-sales hotline, professional metallurgical crane engineers remote troubleshooting.
What Can Henan Mine Crane YX type metallurgical bridge crane Offer You?
| Value Category | Specific Benefits | Description |
| High Temperature Adaptability | Class H insulation + heat insulation cover | Stable operation in furnace high temperature radiation |
| Service Life | Forging-rolling composite wheel | 20% longer wheel life, less maintenance |
| Operation Efficiency | Double trolley synchronous control + PLC | One crane for multi-purpose, improve turnover efficiency |
| Weight Precision | Electronic weighing system | Real-time weight display, overload alarm |
| Operation Safety | Zero position lock + overload protection + limit | Avoid misoperation & overload risks |
| Global Adaptability | International certification & customizable power | Direct export worldwide, no modification |
| Maintenance Cost | Universal parts & long-life components | Lower spare parts & maintenance cost |
| Working Stability | High rigidity bridge & smooth running | Adapt to high-load & high-frequency working condition |
