L-type Offset Gantry Crane

Henan Mine Crane L-type electric hoist gantry crane is a special gantry lifting equipment developed in strict accordance with the standard of electric hoist gantry crane, electric hoist as the lifting mechanism, through the two sides of the outriggers supported by the ground track operation, can complete the vertical lifting of the material, longitudinal and lateral movement, the fetching device to support hooks, grabs, electromagnetic suction cups in a variety of configurations, the outriggers can be cantilevered to extend the scope of operation, can also be designed without cantilevering!

Henan Mine Crane specializes in gantry lifting products for long material lifting and large-angle steering scenarios.

This L-type electric hoist gantry crane is specially optimized for long component lifting and narrow space operation scenarios: the L-shaped outrigger design brings large lifting space and strong spanning ability, and the long materials can pass through the outrigger smoothly, which is suitable for large-angle steering operation.

The whole machine has compact structure and light weight, which makes transportation and installation more convenient; the operating mechanism adopts three-in-one frequency conversion drive, which has smooth starting and stopping, accurate speed regulation, and low running noise.

The equipment can be equipped with a variety of pick-up devices to meet the needs of bulk materials, miscellaneous, steel, long components and other types of material handling, suitable for global machining, building materials, logistics, steel markets and other conventional operating scenarios, is a cost-effective and specialized solutions for long material lifting, space-constrained working conditions.

1. Product core positioning and design standards

The core positioning of MHL type L electric hoist gantry crane is to provide global customers with special solutions for long material lifting, large space spanning, and variable frequency smooth operation. Designed in line with China’s national industry standards for electric hoist gantry cranes, synchronized with the international FEM, EU CE, ISO standards, for the three core needs of long component handling, narrow space, smooth operation, the use of L-shaped shaped outriggers and three-in-one inverter-driven design, to meet the needs of the A3 ~ A5 class of conventional intermittent operations, to match the global indoor workshops, outdoor yards, steel markets and other long material handling conditions.

2. Core structure and function design

1. L-shaped special outrigger structure: Innovative L-shaped outrigger design greatly expands the lifting space and has strong spanning ability, so that long materials and large-sized components can pass through both outriggers smoothly, which is perfectly suited for the lifting of long objects and large-angle steering scenarios.
2. Three-in-one frequency conversion drive: the operating mechanism is equipped with three-in-one frequency conversion drive device as standard, integrating motor, reducer and brake, with smooth speed regulation, no impact when starting and stopping, high operating precision and low failure rate, which is suitable for precise material handling needs.
3. Multi-purpose pick-up device: flexible selection of hooks, grabs, electromagnetic suction cups, hooks for lifting conventional groceries, grabs for loading and unloading bulk materials, electromagnetic suction cups for handling steel, iron, a machine suitable for multiple types of material handling operations.
4. Compact and lightweight structure: the whole machine has a compact structure and light weight, which reduces the transportation and installation cost, and requires less load bearing on the ground track and foundation, so that it can operate stably in old sites and simple tracks.
5. Flexible cantilever configuration: the outboard side of the legs can be configured with a cantilever structure, realizing trans-inside to trans-outside operation and expanding the handling range; the cantilever can also be canceled to adapt to the narrow operating space, which makes it more adaptable to the site.
6. Mature electric hoist lifting mechanism: adopting high-quality special electric hoist, mature technology, stable performance, stable and reliable lifting action, to meet the needs of conventional vertical lifting and lowering of materials.

3. Core product advantages

1. L-type leg space: large lifting space, strong spanning ability, long materials without obstruction through, to solve the industry pain point of long components lifting obstruction, difficult to steering.
2. Frequency conversion drive is smoother: three-in-one frequency conversion operation, no impact of starting and stopping, accurate speed regulation, protection of materials and equipment, and enhancement of operational safety.
3. Lightweight and easy to install: compact structure and light weight, no need for large lifting equipment to install, low rail and foundation requirements, less upfront investment.
4. Wide adaptability of multi-bucket: hook/grapple/electromagnetic suction cups are optional, covering the whole category of material handling for bulk materials, miscellaneous materials, steel materials and long components.
5. Global adaptability and easy to export: support international certification, global grid customization, standardized design and strong compatibility, can be directly exported around the world.

4. Global Adaptation and Application Scenarios

• Application Scenario: Global steel market, machining workshop, building materials processing plant, outdoor yard, logistics and warehousing park, used for lifting long materials such as steel pipes, profiles, beams and columns, loading and unloading of bulk materials such as coal, sand and gravel, and handling of miscellaneous goods such as steel materials and components.
• Standardization: Support CE, ISO9000, GOST, FEM and other international certifications, power supply 220V-660V/50-60Hz is fully customized to meet the global power grid standards.
• Environment: rainproof, dustproof, weatherproof, stable operation in indoor workshop, outdoor open air, high dust environment, coastal salt spray environment can be upgraded with anticorrosion.


5. Global exclusive supporting services

• Provide English/Spanish/Arabic full set of technical data, installation drawings, operation manuals, inverter system commissioning guide;
• 7×24 hours global remote video installation and commissioning guidance, lightweight structure for easy installation and fast assembly;
• Equipment parts centers in Germany, the United States, Malaysia, the United Arab Emirates, electric hoists, three-in-one drive, walking wheels 72 hours of rapid global delivery;
• Multi-language after-sales hotline, professional L-type gantry crane engineers remote troubleshooting, frequency conversion system maintenance guidance.
